LCA results & interpretation AKOUSTI-LINER™ and Acousti-Shield TM
Scope and summary
- Cradle to gate
- Cradle to gate with options
- Cradle to grave
Application
Specifically designed for sheet metal ducts used in heating, ventilating, and air conditioning in North America. It provides an optimum combination of efficient sound absorption, low thermal conductivity, and minimal airstream surface friction. Wall & Ceiling Liner is designed for use as an acoustical and visual barrier for walls and ceilings where a black surface is required. It is primarily used in theaters, sound studios, public concourses and other areas where acoustical treatment is needed. Insulation is delivered to the installation site as one packaged bag containing varying amounts of product.
Functional unit
Reference service life: 75 years. One square meter of installed insulation material, packaging included, with a thickness that gives an average thermal resistance of RSI=1m2·K/W over a period of 75 years.
Reference flow: 0.927 kg of product with no facing options, at a thickness of 0.0386 m to achieve the functional unit. (ASTM C518)
Manufacturing data
Reporting period: October 2015 – September 2016
Location: Shelbyville, IN
Default installation, packaging, and disposal scenarios
At the installation site, insulation products are unpackaged and installed. STape may be used to install duct liner. No material is lost or wasted because scraps are typically used to fill corners or crevices. Packaging waste, made up of paper and plastic, is disposed (plastic: 15% to recycling, 68% to landfill, and 17% to incineration; paper: 75% to recycling, 20% to landfill, and 5% to incineration), and no maintenance or replacement is required to achieve the product's life span. After removal, the insulation is assumed to be landfilled.
What’s causing the greatest impacts
All life cycle stages
The manufacturing stage dominates the results for the acidification, global warming, ozone depletion, smog, ecotoxicity, and fossil fuel depletion impact categories. The remaining impact categories are dominated by the raw materials acquisition stage. Following these two stages, the next highest impacts come from transportation and disposal, which have a similar contribution. However, for smog, the transportation stage is the second highest contributor due to the use of trucks and rail transport. The impact of the raw material acquisition stage is mostly due to the borax, manganese dioxide, and soda ash in the batch and the dextrose in the binder. Since sand and borax are melted in the oven, they are not released into the air as fine particulates and therefore likely actually contribute less than what is calculated in the results tables below. The manufacturing stage shows major contributions to all impact categories. The landfilling of the discarded product contributes to the disposal stage. The only impacts associated with installation and maintenance are due to the disposal of packaging waste, which is the smallest contributor of all the stages.
Manufacturing stage
The energy required to melt the glass and produce the glass fibers is the largest contributor to the manufacturing stage for all impact categories.
Characterized vs. single score results
Due to normalization and weighting, different stages can dominate the characterized and single score results. The batch ingredients sand and borax contribute significantly to the respiratory effects category, causing the raw materials acquisition stage to dominate the mPt results, but not the characterized results. However, they are not released into the air as fine particulates and therefore likely actually contribute less than what is calculated in the raw material acquisition stage. What this means is that the manufacturing stage may have a larger share of the impact than what is displayed in the total impacts by life cycle stage.
Sensitivity analysis
There are no sensitivity results that lead to variations greater than 10% in the LCA results.
Knauf and Manson are committed to providing products that conserve energy and preserve natural resources.
- These products use ECOSE® Technology, which is a plant-based binder adhesive instead of a fossil fuel based binder. ECOSE Technology represents a fossil fuel avoidance equivalent of 100,000 barrels of oil a year for Manson and Knauf Insulation products combined.
- Atmosphere™ Duct Liner and Wall & Ceiling Liner use a special formaldehyde-free black non-woven facer material.
- Our products contain a high degree of recycled content, which translates to 20% less glass melting energy and a 25% reduction in embodied carbon.
- Our utilization of recycled content reduces mining impacts by 60%. In fact, Knauf and Manson products combined use 10 railcars of recycled glass a day.
- All glass fiber made by Manson and Knauf is audited by a 3rd party to ensure biosoluble chemistry from a health and safety standpoint.
LCA results
Life cycle stage | Raw material acquisition | Manufacturing | Transporation | Installation and maintenance | Disposal/reuse/ recycling |
Information modules: Included | Excluded* *In the installation and maintenance phase, packaging waste in module A5 is the only contributor to the potential impacts. |
A1 Raw Materials | A3 Manufacturing | A4 Transporation/ Delivery | A5 Construction/ Installation | C1 Deconstruction/ Demolition |
A2 Transportation | B1 Use | C2 Transporation | |||
B2 Maintenance | C3 Waste Processing | ||||
B3 Repair | C4 Disposal | ||||
B4 Replacement | |||||
B5 Refurbishment | |||||
B6 Operational energy use | |||||
B7 Operational water use | |||||
SM Single Score
Learn about SM Single Score resultsImpacts per 75 years of service | 8.97E-02 mPts | 4.38E-02 mPts | 3.93E-03 mPts | 8.67E-04 mPts | 8.23E-03 mPts |
Materials or processes contributing >20% to total impacts in each life cycle stage | Batch material and binder material production. | Energy required to melt the glass and produce the glass fibers. | Truck and rail transportation used to transport product to building site. | Transportation to disposal and disposing of packaging materials. | Transportation to landfill and landfilling of product. |
TRACI v2.1 results per functional unit
Life cycle stage | Raw material acquisition | Manufacturing | Transportation | Installation and maintenance | Disposal/reuse/ recycling |
Ecological damage
Human health damage
Additional environmental information
Impact category | Unit | |||||
Ecotoxicity | CTUe Comparative Toxic Units of Ecotoxicity Ecotoxicity causes negative impacts to ecological receptors and, indirectly, to human receptors through the impacts to the ecosystem. |
4.24E-02 | 1.72E-01 | 2.43E-02 | 3.53E-04 | 5.42E-03 |
Fossil fuel depletion | MJ, LHV Mega Joule, lower heating value Fossil fuel depletion is the surplus energy to extract minerals and fossil fuels. |
8.18E-01 | 2.08E+00 | 3.70E-01 | 6.47E-03 | 1.10E-01 |
References
LCA Background Report
Knauf Insulation and Manson Insulation Products LCA Background Report (public version), Knauf 2018. GaBi 7, GaBi 2017 database.
PCRs
ISO 21930:2017 serves as the core PCR along with EN 15804 and UL Part A.
ULE PCR Part A: Life Cycle Assessment Calculation Rules and Report Requirements v3.1
May 2, 2018. Technical Advisory Panel members reviewed and provided feedback on content written by UL Environment and USGBC. Past and present members of the Technical Advisory Panel are listed in the PCR.
ULE PCR Part B: Building Envelope Thermal Insulation
Version 2.0, April 2018. PCR review conducted by Thomas Gloria, PhD (chair, [email protected]); Andre Desjarlais; and Christoph Koffler, PhD.
ULE General Program Instructions v2.1, April 2017
ISO 14025, “Sustainability in buildings and civil engineering works -- Core rules for environmental product declarations of construction products and services”, ISO21930:2017
Download SM Transparency Report, which includes the additional EPD content required by the UL Environment PCR.
SM Transparency Reports (TR) are ISO 14025 Type III environmental declarations (EPD) that enable purchasers and users to compare the potential environmental performance of products on a life cycle basis. They are designed to present information transparently to make the limitations of comparability more understandable. TRs/EPDs of products that conform to the same PCR and include the same life cycle stages, but are made by different manufacturers, may not sufficiently align to support direct comparisons. They therefore, cannot be used as comparative assertions unless the conditions defined in ISO 14025 Section 6.7.2. ‘Requirements for Comparability’ are satisfied. Comparison of the environmental performance of building envelope thermal insulation using EPD information shall be based on the product’s use and impacts at the building level, and therefore EPDs may not be used for comparability purposes when not considering the building energy use phase as instructed under the PCR. Full conformance with the PCR for building envelope thermal insulation allows EPD comparability only when all stages of a life cycle have been considered, when they comply with all referenced standards, use the same sub-category PCR, and use equivalent scenarios with respect to construction works. However, variations and deviations are possible. Example of variations: Different LCA software and background LCI data sets may lead to different results upstream or downstream of the life cycle stages declared.
